    Puppet Server & Client Installation CentOS 6.x

    Puppet Server & Client Installation CentOS 6.x

    Step-by-step guide to setting up a Puppet Server and agent on CentOS 6.4, including Apache configuration and SSL certificate management.

    Suggest editsRSSFollow on Google

    This post assumes that you are starting with a clean minimal CentOS 6.4 64bit server and you have a full hostname set.

    Puppet Server Installation ……

    Puppet Server & Client Installation CentOS 6.x 1/4
    # Hostname - Make sure the host name it set to puppet.yourdomain.com and that you replace references in this file
    # Install puppet & epel repos
    yum install -y http://yum.puppetlabs.com/el/6/products/i386/puppetlabs-release-6-6.noarch.rpm http://www.mirrorservice.org/sites/dl.fedoraproject.org/pub/epel/6/i386/epel-release-6-8.noarch.rpm
    # Download puppet-server from Puppet Labs, apache and necessary dependencies
    yum install -y vim-enhanced puppet-server httpd httpd-devel mod_ssl ruby-devel rubygems gcc-c++ curl-devel zlib-devel make automake openssl-devel rubygem-rack rubygem-passenger-native-libs rubygem-passenger-native rubygem-passenger rubygem-fastthread libev mod_passenger git
    # Start Puppet-Server
    /etc/init.d/puppetmaster start
    # Set Puppet Master to run on startup
    puppet resource service puppetmaster ensure=running enable=true
    # Create the directory structure for Puppet Master Rack Application
    mkdir -p /usr/share/puppet/rack/puppetmasterd
    mkdir /usr/share/puppet/rack/puppetmasterd/public /usr/share/puppet/rack/puppetmasterd/tmp
    cp /usr/share/puppet/ext/rack/files/config.ru /usr/share/puppet/rack/puppetmasterd/
    chown puppet /usr/share/puppet/rack/puppetmasterd/config.ru
    # Create the VHOST for puppet master
    cat > /etc/httpd/conf.d/puppetmaster.conf << APACHE_CONFIG
    PassengerHighPerformance On
    PassengerMaxPoolSize 6
    PassengerMaxRequests 1000
    PassengerPoolIdleTime 600
    Listen 8140
    <VirtualHost *:8140>
    SSLEngine On
    # Only allow high security cryptography. Alter if needed for compatibility.
    SSLProtocol All -SSLv2
    SSLCipherSuite HIGH:!ADH:RC4+RSA:-MEDIUM:-LOW:-EXP
    SSLCertificateFile /var/lib/puppet/ssl/certs/puppet.yourdomain.com.pem
    SSLCertificateKeyFile /var/lib/puppet/ssl/private_keys/puppet.yourdomain.com.pem
    SSLCertificateChainFile /var/lib/puppet/ssl/ca/ca_crt.pem
    SSLCACertificateFile /var/lib/puppet/ssl/ca/ca_crt.pem
    SSLCARevocationFile /var/lib/puppet/ssl/ca/ca_crl.pem
    SSLVerifyClient optional
    SSLVerifyDepth 1
    SSLOptions +StdEnvVars +ExportCertData
    # These request headers are used to pass the client certificate
    # authentication information on to the puppet master process
    RequestHeader set X-SSL-Subject %{SSL_CLIENT_S_DN}e
    RequestHeader set X-Client-DN %{SSL_CLIENT_S_DN}e
    RequestHeader set X-Client-Verify %{SSL_CLIENT_VERIFY}e
    DocumentRoot /usr/share/puppet/rack/puppetmasterd/public/
    <Directory /usr/share/puppet/rack/puppetmasterd/>
    Options None
    AllowOverride None
    Order Allow,Deny
    Allow from All
    </Directory>
    </VirtualHost>
    APACHE_CONFIG
    # Sort out the services
    /etc/init.d/puppetmaster stop
    /etc/init.d/httpd start
    chkconfig puppetmaster off
    chkconfig httpd on
    # check its listening
    netstat -ln | grep 8140
    # bosh

    Install the agent ……

    Puppet Server & Client Installation CentOS 6.x 2/4
    # Add the Puppetlabs & VIM !!!
    yum install -y http://yum.puppetlabs.com/el/6/products/i386/puppetlabs-release-6-6.noarch.rpm vim-enhanced
    # Disable the repo
    sed -i ‘s/enabled=1/enabled=0/g’ /etc/yum.repos.d/puppetlabs.repo
    # Install the agent
    yum install -y puppet - enablerepo=puppetlabs*
    # Configure the agent
    cat >> /etc/puppet/puppet.conf << CONFIG
    server = puppet.yourdomain.com
    report = true
    pluginsync = true
    CONFIG
    # Daemonize it and make it start on boot
    chkconfig puppet on
    puppet agent - daemonize

    This will have sent the client certificate to the master server, all you have to do now is sign it. On Puppet Master ……

    Puppet Server & Client Installation CentOS 6.x 3/4
    puppet cert list
    puppet cert sign - all

    and then test on the Puppet client ……

    Puppet Server & Client Installation CentOS 6.x 4/4
    puppet agent - test
